Automatic transfer switch with full electrical protection from Southwire ® is designed with dual 80A Chint contactors that include a mechanical interlock to ensure safe operation. The mechanical interlock design prevents both contactors from engaging at the same time. The rugged plastic box provides a safe and secure enclosure for the transfer switch device. Avoid the potential of corrosion, sharp edges, and risk of an energized enclosure that comes with a metal Transfer Switch; Transfer Power Between Shore And RV Generator; Automatic; 120/ 240 Volt; 50 Amp; 8.84 Inch Width x 13-1/2 Inch Height x 5.21 Inch Depth; Protects Against Excessive Voltage/ Mis-Wired Pedestal/ Open Neutral/ Open Ground/ High And Low Frequency And Reverse Polarity
Attributes
- Type: Automatic
- Function: Transfer Power Between Shore And RV Generator
- Voltage: 120/ 240 Volt
- Ampere Rating: 50 Amp
- Length (IN): 8.48 Inch
- Width (IN): 5.21 Inch
- Height (IN): 13-1/2 Inch
- Color: Black
- Mounting Type: Wall Mount
Features & Benefits
- Generator Dominant And Transfers To Generator Power Automatically When Energized After 30 Second Delay
- Time Delay At Power Up
- Featured With LED Indicator For Reverse Polarity And Open Ground Protection
- UL-Listed While Capable Of Up To 50A
- Protects Against Miswired Pedestal, Power Surge And Voltage Anomalies
- Limited 1 Year Warranty
