Description
FPS-G7W525EQ – G7 SS Hanger + Walbro 525LPH E85 Pump, Quick-disconnect QD
MSRP
FEATURES:
All stainless-steel construction
Non-tapered pump outlet tube for maximum flow / performance.
Tubes have smoother radius bends for maximum flow / performance
Dual 14-gauge circuits (vs. factory single 16-gauge ) for double current handling (28 amps) and reliability
Modular wiring harness allows for simple repairs
Includes a new stainless-steel locking ring, OE-type tank gasket
Upgraded grounding system
Walbro F90000285 525LPH E-85 certified high-pressure/volume pump pre-installed
30-micron graded-media filter sock installed
New-style 90 ohm ceramic level sender resistor (digital dash 120-ohm sensor optional) (1)
New 30-amp power connector for improved performance (2)
Custom SS removable pump mount
Quick-disconnect outlets (JIC adapters optional)
(1) For use with analogue dash only. Digital dash cars will need to add our optional 120 ohm level sensor.
(2) This hanger has a Delphi MP 280-series power connector so it will not plug directly into older hotwire harnesses. Our new heavy-duty FPWH-076 hotwire harness is highly recommended to reliably support this high-performance hanger Customers who can’t afford to upgrade their current hotwire harnesses may use our FPAH-076 to adapt the power connector on this hanger to the factory-type Weather-Pack connector found on first-generation hotwire harnesses. This hanger MUST NOT be run off of the factory wiring PERIOD!
The factory return are lines too restrictive and not able to handle the fuel volume of this pump. This will cause the base fuel pressure to rise without allowing it to be turned down. The return line must be upgraded to -6 Teflon-lined hose.
We offer complete line kits shown under Add-ons on the right side of this page. For customers who have already upgraded their lines QD to JIC adapters are also listed.
Similar to Delphi FL0207, Spectra Premium FG156A
